Product Summary
The MC33364D2R2G is a variable frequency SMPS controller that operates in the critical conduction mode.
Parametrics
Absolute maximum ratings: (1)Power Supply Voltage (Operating):16V; (2)Line Voltage:700V; (3)Current Sense, Compensation,Voltage Feedback, Restart Delay and Zero Current Input Voltage:-1.0V to +10V; (4)Zero Current Detect Input:±5.0mA; (5)Restart Diode Current:5.0mA; (6)Operating Junction Temperature:150℃; (7)Operating Ambient Temperature:-25℃ to +125℃; (8)Storage Temperature Range:-55℃ to +150℃.
Features
Features: (1)Lossless Off-Line Startup; (2)Leading Edge Blanking for Noise Immunity; (3)Watchdog Timer to Initiate Switching; (4)Operating Temperature Range -25℃ to +125℃; (5)Shutdown Capability; (6)Over Temperature Protection; (7)Optional/Adjustable Frequency Clamp to Limit EMI; (8)Pb-Free Packages are Available.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MC33364D2R2G |
ON Semiconductor |
Current Mode PWM Controllers Variable Frequency SMPS |
Data Sheet |
|
|
||||||||||||
